ProEdge CNC External Corner Grinding Press

Name: ProEdge CNC External Corner Grinding Press
Brand: Star Power
Price: 1 USD

Quality ProEdge CNC External Corner Grinding Press for sale

Brand Name : Star Power

Model Number : ECGP-3000

Certification : CU, ISO

Place of Origin : Guangdong, China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C,T/T

Supply Ability : 30 Set/Sets per Year

Delivery Time : 30-50 working days

Packaging Details : Seaworthy Packing

Contact Now

ProEdge CNC External Corner Grinding Press

I. About Us

Company Introduction Founded in 2022, Foshan Star Power Technology Co., Ltd. is located in Foshan, a city renowned for its pottery and martial arts. With a registered capital of 5 million yuan, our company focuses on a wide range of businesses, including information system integration, machinery and metal product sales, and import-export services. In the field of sink production lines, we offer advanced solutions. Our equipment combines high-precision CNC technology with efficient production processes. We are committed to providing customers with complete sets of sink production line equipment, which can achieve operations such as laser cutting, bending, and welding. This not only ensures the high-quality manufacturing of sinks but also meets the production needs of different batch sizes, helping our clients improve production efficiency and product quality.

ProEdge CNC External Corner Grinding Press

II. Product Introduction

The ECGP-3000 ProEdge CNC External Corner Grinding Press is a precision-engineered industrial machine designed for automated grinding and polishing of external corner edges in metal fabrication processes. Characterized by its robust C-frame structure and vibrant blue industrial finish, this machine integrates advanced pneumatic actuation with precision guiding systems to deliver consistent 90° corner finishing results across various sheet metal materials.

Core Mechanical Structure

Heavy-Duty Frame: Single-column C-type construction with reinforced steel base (8mm thickness) ensuring minimal vibration during high-speed grinding operations
Precision Grinding Head: Tungsten carbide grinding wheel (Φ125mm) with diamond coating, mounted on a dual-guide rail system for vertical stroke accuracy of ±0.02mm
Pneumatic Actuation: 0.6-0.8MPa air-powered cylinder with 150mm stroke, providing adjustable grinding pressure (50-300N) via pressure regulator valve
Workpiece Fixture: Quick-change triangular positioning jig (maximum workpiece thickness: 3-12mm) with rubberized clamping pads to prevent material deformation
Control Panel: IP54-rated electrical box featuring emergency stop button, start/stop toggle, pressure gauge, and cycle counter

Technical Specifications

Grinding Capacity: External corners of metal sheets (mild steel, stainless steel, aluminum alloys)
Corner Angle Tolerance: ±0.5° after processing
Surface Finish: Ra 1.6μm (standard) to Ra 0.8μm (with fine-grit wheel)
Cycle Time: 8-12 seconds per corner (depending on material thickness)
Power Supply: AC 220V ±10%, 50Hz, single-phase
Air Consumption: 250L/min at 0.7MPa working pressure
Machine Dimensions: 650mm (L) × 580mm (W) × 1200mm (H)
Net Weight: 280kg
Safety Features: Two-hand start protection, overload pressure relief valve, protective guard around grinding area

Operational Advantages

Semi-Automatic Operation: Foot pedal control for hands-free workpiece positioning, improving operator efficiency by 40% compared to manual grinding
Rapid Tool Change: Quick-release wheel hub allows grinding wheel replacement in under 2 minutes
Adjustable Parameters: Pressure regulator and stroke limiter enable customization for different material hardness (e.g., aluminum vs. carbon steel)
Space-Efficient Design: Compact footprint ideal for small to medium-sized fabrication workshops
Low Maintenance: Sealed linear bearings and lubrication-free pneumatic components reduce service requirements

Typical Applications

Sheet metal enclosure manufacturing (electrical cabinets, control panels)
Architectural metal fabrication (window frames, door edges)
Furniture hardware production (aluminum profiles, steel brackets)
Automotive component processing (body panels, chassis parts)
HVAC ductwork finishing (flange corners, connection edges)

The ECGP-3000 combines industrial-grade durability with precision finishing capabilities, making it an essential tool for metalworking facilities requiring consistent corner quality and increased production throughput. Its distinctive blue powder-coated finish provides corrosion resistance suitable for workshop environments, while the integrated safety systems ensure compliance with CE machinery directives.

Parameter	Specification
Product Name	ProEdge CNC Corner Grinding Press
Model	ECGP-3000
Processing Capacity	External metal corners (3-12mm thickness)
Surface Finish	Ra 0.8-1.6μm
Cycle Time	8-12 sec/corner
Grinding Pressure	50-300N (adjustable)
Power Supply	AC 220V, 50Hz
Air Requirement	0.6-0.8MPa, 250L/min
Dimensions	650×580×1200mm (L×W×H)
Weight	280kg
Safety Features	Two-hand start, emergency stop, protective guard

VI. Customer Benefits

• Quality Upgrade: Precise grinding improves product details, helping customers create high-value-added products and enhance market competitiveness.

• Cost Reduction & Efficiency Improvement: Automated operation reduces labor costs, and efficient processing increases production capacity, enabling quick response to order demands.

• After-Sales Guarantee: As the source manufacturer, STARPOWER provides 7x24 technical support, free installation and commissioning, and a 1-year warranty (adjust according to actual policies), ensuring customers have no worries.

Choosing STARPOWER's Vertical Seam Internal Round Corner Grinding Machine means more than just purchasing a device; it means partnering with an industry-experienced technical expert. We will support your production processes to be more efficient and your product quality to be more excellent with professional products and services.
